Twin Shaft Paddle Non-Gravity Dry Mortar Mixer

1.Conjoined direct-connected drive structure, stable operation, strong bearing capacity and high stirring efficiency.

2.The double shaft rotates in the opposite direction at the same speed, and the special paddle makes the stirring material move axially and radially to achieve uniform stirring.

3.A wide range of applicable materials, widely used in building materials, chemicals, coatings and other fields, the mixing time is short, the discharge speed is fast.

Working Principle

1.The core of the equipment consists of a pair of mixing shafts mounted horizontally within a W-shaped or U-shaped vessel; the two shafts rotate in opposite directions at the same speed.

2.Weightless Mixing: High-speed rotation of specially angled paddles generates centrifugal force, propelling materials radially into the space above the vessel; at the apex of their trajectory, the materials enter a momentary state of "weightlessness."

3.Compound Motion: In this state, driven by the paddles, the materials undergo multi-dimensional compound movements—including vertical tumbling, lateral interlacing, and axial advancement—resulting in convective, shear, and diffusive mixing.

4.High Efficiency and Uniformity: The paths of the dual-shaft paddles intersect and intermesh with a staggered arrangement. Materials in the overlapping zones are subjected to shearing and separation forces, enabling even materials with significant differences in specific gravity and particle size to be mixed uniformly within a very short time.

Used for

Used for Masonry  mortar,  Plastering  mortar(bottom),  Floor  mortar,  Caulking agent mortar(black),  Seaming agent mortar,  Caulking agent mortar(white), Seaming agent mortar,  Thermal mortar,  Self-leveling mortar,  Whitewashed plaster(bottom),  Cement plaster mortar, External putty powder,Chemical powder etc.
